Full LED SPEC

Main Specifications


        Pixel Pitch   6mm

Pixel Density   27,777dots/㎡

Color Configuration   1R1G1B 3in1

LED Package   SMD3535

Cabinet Resolution   96dots x 96dots

Cabinet Size   586mm x 586mm - 1.8ft.X1.8ft.

Dre Duty   1/8scan

      Cabinet Weight   10.25kg/22.5lbs.

Brightness   >6,500nits

Best Viewing Angle   H: 120°, V: 120°

Best Viewing Distance   >6m

Refresh Rate   2,000HZ

Flame Rate   120frame/sec.

Grey Scale   256levels of Each Color

Color Grade   16.7M Colors

Working Voltage   AC110V/220V±10%, 50HZ

Working Temperature   -20℃ - +60℃

Storage Tempreature   -40℃ - +80℃
     Operation Humidity   10% - 95%

Blind Spot Rate   <1/10,000

MTBF   >10,000hours

Life Span   >100,000hours

Waterproof   IP65

Max. Power Comsuption   1,200W/㎡     Ave.

Powe Comsuption   400W/㎡

Control Mode   Asynchronous/Synchronous/3G/Wifi

Operation System   Win98, Win2000, XP, Win7, etc
     Input Source   All Format(JPEG, AVI, MP4, RMVB, etc)

Certificate   CE/LVD/RoHS/etc

PRODUCT SPECIFICATIONS

LED Module

P6 Outdoor SMD3535

Pixel Pitch: 6mm
Color Configuration: 1R1G1B 3in1
LED Package: SMD3535
Cabinet Resolution: 96dots x 96dots
Cabinet Size: 586mm x 586mm - 1.8ftX1.8ft.
Cabinet Weight: 10.25kg/22.5lbs
Drive Duty: 1/8scan Constant Current.
